Specificities
■Embedded power beam and door body embedded installation, and keep the same level with the wall, more beautiful, rich in overall feeling.
The surface with the wall is more beautiful and full of overall sense.
Adopting unique high-tech design, good sealing performance, preventing cross-contamination, maximizing clean performance, and airtight performance in line with national standards.
The sealing performance is good, preventing cross-contamination and maximizing clean performance, and the airtightness is in line with the national standard.
(JG/T257-2009), level 8 standard (the highest level).
The overall operation is light and peaceful, with good indoor and outdoor sound insulation effects.
■Environmental protection and energy saving: The door is solid and thick, easy to open and close, reduces air circulation, and prevents cold wind and dust.
It can prevent cold wind and dust from entering places with clean requirements and maintain constant temperature and humidity.
■The humanized barrier-free design allows patients and carts to pass safely, is easy to use and provides convenience.
Technical parameters
Width of single door leaf | 600-2000mm |
Installation method | Built-in |
Motor | DC24V 60W/DC brushless |
Opening speed | 30-60cm/s |
Closing speed | 30-60cm/s |
Hold-open time | 0-9s adjustable |
Manual opening force | 30N |
Ambient temperature | -20~+50℃ |
Supply voltage | AC200-250V 50/60Hz |
Airtight rating | Level 8 |
