Hollow Double-Layer Glass Cleanroom Window

Details

Model：SCC-50 type-100 type

Specification: conventional, non-standard, can accept special requirements of the user design

Material: Aluminium alloy and SUS304 stainless steel are used for the window frame; 5mm tempered glass is used.

Seal: sealing strip, silicone

Colour: black printing, white printing

Usage

Suitable for pharmacy, food, biology, electronic factory and other workshops.

Characteristic

Double printing clean windows have good airtight performance, walls and windows in the same plane, flexible installation, beautiful and so on. It can be made according to different wall thicknesses, especially suitable for 50~100mm thick colour steel plates, double windows, hollow type, and moisture-proof types.

Performance

Sound insulation: to meet people's needs for light, landscape, decoration, and environmental protection, general hollow glass can reduce the noise by about 30 decibels, and two full of inert gas hollow glass can be reduced based on the original 5 decibels or so, you can reduce the noise of 80 decibels to 45 decibels is extremely quiet degree.

Good thermal insulation properties: thermal conductivity system K value, a single piece of 6mm glass K value of 5.75kcal/mh ° C, the general insulating glass K value of 1.4-2.9kcal/mh ° C, for the argon and sulphur fluoride gas-filled insulating glass K value can be reduced to a minimum of 1.19kcal/mh ° C, argon is mainly used to reduce the thermal conductivity of K value, sulphur difluoride gas is Argon gas is mainly used to reduce the K value of heat conduction, and sulphur difluoride gas is mainly used to reduce the dB value of noise, the two gases can be used alone, or mixed according to a certain proportion.

Anti-frosting: In winter, when the temperature difference between indoors and outdoors is large, single-glass doors and windows will have a frost phenomenon, while insulating glass is frost-free.

Technical parameters

Remarks: We can accept customers' requirements to make non-standard products with different specifications and models, and the doors and windows can be made of different shapes and grades of glass, such as tempered glass, fireproof glass, and bulletproof glass.
