Use
It is suitable for workshops such as pharmaceutical factories, electronic factories, hospital operating theatres and so on.
Features
It opens quickly and smoothly. It is especially suitable for clean room logistics, people flow frequently in and out of the passageway, it can quickly isolate the clean room inside and outside the airflow, to maintain the cleanliness of the air inside the clean room air.
Particulars
Model：YYQ-50-100 type
Specification: conventional, non-standard, can accept special requirements of the user design
Material: door frame is made of SUS304 stainless steel brushed plate, colour steel plate, baked enameled steel and mithril plate; door page is made of SUS304 stainless steel brushed plate, colour steel plate and baked enameled steel.
Filling: flame retardant paper honeycomb, aluminium honeycomb, rock wool sandwich, polyurethane foam
Windows: square, oval, single glass, double printed glass
Surface: brushed, baked paint
DDS access control: foot-sensing, hand-sensing, head-sensing, smart card, magnetic card, barcode, fingerprint, palm print, touch, etc.
Seal: airtight strip
Colour: Colour steel plate milky white, dark blue, teal, etc. Baking can be accepted on request.
Technical parameters
| Door frame profiles | Wrapped frame type, flat frame type, pairs of clips type (can be customised according to customer needs) | |||
| Frame Advantages | According to the actual site of any size opening | |||
| Materials | Thickness of the steel plate of the door frame:1.5mm, Thickness of the steel plate of the door leaf:1.0mm. | |||
| Surface treatment | Spraying, and baking paint (colour can be customized according to customer's requirement) | |||
| Wind Pressure Resistance P3(KPa) |
2.8 | Acoustic performance | Rw=33dB Grade III (GB/T8485-2008) | |
| 100.8KPa | Anti-collision performance | Comply with GB/T20909-2007 | ||
| Q2=1.0/2.1 | Thermal insulation performance | Heat transfer coefficient K=2.8W/(m2.K)Grade V | ||
| Filling | Flame retardant paper honeycomb | Fireproof aluminium honeycomb | Rock wool | Polyurethane foam |
| Hardware | Yatai custom stainless steel hinge, aluminium alloy hinge | |||
| YT one-piece executive lock | YT split actuator lock | Pressure lock | Available according to the customer's option | |
| Surface treatment of door frame | Sand electric white | Spraying | Electrophoresis | Available according to the customer's option |
